HOME > COLUMNS > Design #700-7 - Tuscan Order - (Chop & Spray Fiberglass) Column - Plain, Round, Tapered - Includes Fiberglass Tuscan Capital & Base Molding / Plinth
Design #700-7 - Tuscan Order - (Chop & Spray Fiberglass) Column - Plain, Round, Tapered - Includes Fiberglass Tuscan Capital & Base Molding / Plinth
Item Number: FGX-PL-TP-A-TSC-FG-7
TUSCAN ORDER
CHOP & SPRAY FIBERGLASS COLUMNS
(PLAIN, ROUND, TAPERED)
DESIGN 700-7
– COLUMN SIZES –
BOTTOM DIAMETERS: 14" – 36"
OVERALL HEIGHTS: 8' – 28'
MATERIAL & MANUFACTURING PROCESS
Composed of high-density fiberglass and polyester resin material.
Each column shaft, capital & base molding / plinth is sanded and
primed. Custom molds can be created for your unique column
specifications. Our Chop-and-Spray Fiberglass Columns are great
for commercial projects and residential projects.
COLUMN SHAFT
Fiberglass column shaft mixed with polyester resin. Column shaft is
plain/smooth and architecturally tapered (bottom third of the shaft
is straight, with the remaining 2/3 tapering to the neck). Paint grade
column shaft (includes gel coat). Shaft can be cut down to your
desired overall height by trimming the bottom of the shaft only with
a circular saw equipped with a masonry blade. Classic astragal
(bead) molded onto the column shaft.
CAPITAL, BASE MOLDING & PLINTH
Tuscan capital, base molding & plinth included – made from fiberglass
material. Please also note that column components are designed to
wrap around the shaft as decorative sleeves – they do not add height.
Please see below for Decorative Capital options and alternative base
molding / plinth designs. Please see options below.
|
LOWER/BOTTOM DIAMETER: 14" - 36"
UPPER/TOP DIAMETER: 12" - 30"
OVERALL HEIGHT: 8' - 28'
WALL THICKNESS: 1/4"
INTERIOR ROUND CLEARANCE: Dependent on size of column
INTERIOR SQUARE CLEARANCE: Dependent on size of column
ACCEPTABLE TOLERANCE: 1/8"
SHAFT WEIGHT: Dependent on size of column
LOAD-BEARING CAPACITY: Dependent on size of column
|
|
|
FLEXIBILITY:
• Able to be split & tabbed for reassembly
• Shaft will have proper 1/3, 2/3 taper (entasis)
• Great for Commercial & Residential projects
• Assortment of capitals, bases & plinths available
SHIPPING:
RESTOCKING:
• Yes, excluding custom and altered products
• Fee will be applied
|
| Please contact a Chadsworth Sales Consultant for additional information. 1-800-486-2118 or sales@columns.com |
|
